| Return Postage Will Be Paid By | Buyer |
| Returns Accepted | Returns Accepted |
| After Receiving The Item, Your Buyer Should Cancel The Purchase Within | 30 days |
| Manufacturer Part Number | gammatronix |
| Brand | gammatronix |
Integrated 5mm LED 12v Battery charge / level indicatorExtended Wire VersionAllows LED to be placed in confined areas NEVER be left WITHOUT WARNING that your Bike, Car, Caravan, Camper, RV, electrical equipment, RC model, Bait Boat, or even that battery powering your light in the shed, is going 'Flat' This versatile unit can be used wherever you have a 12v lead-acid battery (Gel and matt types included) or charging system. One wire to battery positive, one to negative. We couldnt have made it simpler. Check the specification!...............Small mounting footprint using 5mm LED. This version had 50mm extension wires to allow flexible mounting away from control PCBUses same measurement system as our most popular 'E' 10mm unit, but in a compact 5mm packageWorks with all Lead acid, fibre mat or gel cells, and all other batteries that operate within the set rangesProtects and warns against Undercharging, Overcharging, and 'flat' batteries.12v DC operation at 5mA or less consumption.TWO operating ranges via 'yellow wire'Tri colour (Red, Green, Yellow) 5mm LED with seperate optional bezelMounts in 6.5mm hole with bezel, or 5mm without (using your own mounting system)Approx 20mm behind control panel when mounted, and pcb can be flexed through 90 degrees to further reduce depthUnit will operate down to 3.7v and up to 16v.Multiple oversampling - unit takes 10+ readings to obtain greatest accuracy.Built in hysteresis to prevent 'strobing LED' when unit is at changeover point.Supplied with fitted connection leadsComprehensive fitting instructions The tri-colour LED will illuminate in different colours, solid or flashing, selected by the yellow mode wire. One of two modes, as per the table below, show the state of your battery. "Charging Mode" increases the point at which the LED lights to 13.2v, which will only be attained if your alternator or charging device is supplying power to your battery. Charging Mode (Yellow wire cut) Level Indicator Mode (Yellow wire intact)Red /Grn FlshGrnYellYell FlshRedRed Flsh GrnYellYell FlshYell Fast FlshRedRed FlshRed Fast Flsh>15.2v13.2v11.8v11.5v11.2v<11.2v 12.1v11.8v11.5v11.2v11.0v10.7v<10.7v The Yellow light from a 5mm tri-colour LED may vary in shade according to viewing angle. Rotate the LED in its mounting at installation time to provide the best viewing experience.The unit may be configured at installation time to run in one of two modes, selected by cutting, or leaving intact, a yellow wire 'loop' at the rear of the unit. It is permissible to cut and extend the yellow wires ro a remote switch should the user wish to change modes in operation.The unit fits into a 6.5mm hole, into which its bezel (shown on LED in the photo) inserts, and the LED clips into the bezel from behind.___A standard version without LED extension leads is available from our other listings or Ebay store___Buy with confidence, from a UK Limited Company. We have a no arguments return guarantee.Check out our Ebay shop for other battery monitor models. FOR OVERSEAS BUYERS :Shipping : Please note that Ebay postage estimator (beyond our control) will often give a WILD range of dates for you to expect receipt of your unit. Economy post may often be with you in 6-10 days, BUT DOES NOT HAVE TRACKING and may on occasion take longer, If you require tracked delivery, please upgrade to the 16 dollar postage option which will provide you with a tracking number, and a faster shipment time.
